Heating Mantle Combined Unit with Stirrer

Availability:

In stock

35,000.0038,800.00


Model No.(230V 50Hz):2500.DNEU.01, Model No.(230V 50Hz):2500.DNUS.01, Mantle Capacity (ml):100ml, W:450, No. of Position of regulator: 3/3 | Model No.(230V 50Hz):2500.DNEU.02, Model No.(230V 50Hz):2500.DNUS.02, Mantle Capacity (ml):250ml, W:450, No. of Position of regulator: 3/3 | Model No.(230V 50Hz):2500.DNEU.03, Model No.(230V 50Hz):2500.DNUS.03, Mantle Capacity (ml):500ml, W:600, No. of Position of regulator: 3/3

Model No.(230V 50Hz) Model No.(230V 50Hz) Mantle Capacity (ml) W No. of Position of regulator
Qty Enquiry
2500.DNEU.012500.DNUS.01100ml450 3/3
2500.DNEU.022500.DNUS.02250ml450 3/3
2500.DNEU.032500.DNUS.03500ml600 3/3
  • Heating Mantle Combined unit made of M. steel
  • Variable knob for heat power control with on/off.
  • Variable Knob for stir speed control with on/off.
  • Mantle knitted with glass fibre yarn
  • Provides uniform heating to flasks
  • For Round Bottomed Flasks as per DIN – 12347
  • Easy maintenance
  • Life long
  • Single position also available with Metallic Stand 1600.EU




Technical Specification:

Heating Mantle Body : Made of Mild Steel
Heating mantle material : Glass fibre yarn
Mantle Capacity : To hold Standard round bottom flasks upto 500ml
Valuable stirring speed
: 750 RPM
Temperature Range : Approx. 400°C
Heating Control : Electronic power regulator
Stir Control : Electric regulator
Dimension : 495x246x200
Permissible Ambient Temperature : 5- 40 °C
Permissible relative moisture : 80%
IP Class : 10

Included Accessory:

Cat. No. Accessories
2000.200.01 Vertical Rod stainless steel length 542mm, ∅ 9.8mm
2000.200.02 Horizontal Rod stainless steel length 972mm, ∅ 9.8mm
2000.200.03 5 Boss Head
2000.200.04 3 clamp




SINGLE SOXHLET EXTRACTION WITH STIRRER

Extraction unit metal stand with heating mantle stirrer

Model No. (230V, 50Hz) Capacity (ml) Watts Fuse Amp. No. of position of regulator Price/Piece
1600.DNEU.01* 100 170 1 1/1 18200
1600.DNEU.02* 250 170 1 1/1 18500
1600.DNEU.03* 500 220 2 1/1 19900

Glass Accessories:

Cat No. Extractor Cap (ml) Extractor Socket Extractor Cone Flask Cap. Condenser Type Connector Pcs/Pack Price/Piece
210.202.03 60 34/35 24/29 150 ALLIHIN Screw Thread 1 1450
210.202.04 100 45/40 29/32 250 ALLIHIN Screw Thread 1 1700
210.202.06A 200 50/42 24/29 500 ALLIHIN Screw Thread 1 2800
210.202.08 500 60/46 29/32 1000 ALLIHIN Screw Thread 1 6000






Temp RPM Vessel Capacity Mantle Material
400° C upto 750 RPM 100-500ml Glass fibre yarn
