| Item Code | Volts | Hz |
| ||
|---|---|---|---|---|---|
| DAN.NACOM.04 | 220–240V AC | 50/60 |
| Capacity | 6 / 8 tubes |
| Compatible Tube Sizes | 42 mm OD, 300 mL Kjeldahl tubes |
| Temperature Range | Ambient to 450 °C |
| Temperature Accuracy | ±1 °C |
| Heating Module Material | Aluminium alloy high-temperature block |
| Temperature Control | PID-based point and curve control |
| Construction | High-temperature digestion block with resistant chemical-pathways |
| Auto Scrubber | Automatic drain and refill after each digestion cycle |
| Power Supply | 220–240 V AC, 50/60 Hz |
| Power Consumption | 1.8–3 kW |
Related products
- Kjeldahl Instruments
Advanced 3-in-1 Nitrogen Analysis System
INTEGRATED WORK STATION FOR NITROGEN ESTIMATION
- Advanced 3-in-1 Nitrogen Analysis System integrating Digestion, Distillation, and Auto Titration in one compact platform.
- 7-Inch Capacitive Full-HD Touch Display with a modern GUI interface for seamless control and real-time process monitoring.
- Independent Digestion Operation that runs without any requirement from distillation or titration systems.
- Distillation & Titration – Selectable but Dependent: Both can operate individually; titration requires distillation output; ensures accurate Distillation → Titration sequence.
- Parallel Workflow Capability allowing digestion to run independently while distillation and titration proceed automatically in order.
- Semi-Automatic Reagent Handling with automatic suction and feeding of reagents during operation.
- Inbuilt Scrubber: Absorbs digestion fumes for safer, cleaner operation.
- Separate Containers for All Reagents: Diluent, Alkaline Solution, Boric Acid, Titrant, and Titration Color/Indicator.
- Large-Capacity Reagent Bottles for extended operation with minimal refilling frequency.
- Auto Scrubber Water Drain & Refill after every digestion cycle for consistent performance and reduced manual work.
- Auto Steam Generator Refill with proximity-based water level sensing for safe and uninterrupted distillation.
- High-Efficiency Steam Generation for faster recovery, consistent distillation output, and reduced energy usage.
- Precision Auto Titration System with accurate endpoint detection and stable titrant dispensing for repeatable results.
- Chemical-Resistant Tubing & Components designed for long-life operation even in harsh laboratory environments.
- Low Maintenance Design with easy-to-access service areas and tool-less assembly for cleaning and tubing replacement.
- Smart Error Detection with alarms for low water, low reagents, temperature faults, and system abnormalities.
- Over-Voltage, Over-Temperature & Dry-Run Protection ensuring operational safety.
- High-Temperature Resistant Digestion Block for uniform heating and long-term durability.
- Energy-Optimized System for reduced power consumption without compromising performance.
- Flexible Operation Modes:
- Digestion Only
- Distillation Only
- Titration Only (after distillation)
- Distillation + Titration Combined
- Full Cycle (Digestion → Distillation → Titration)
- Designed for Heavy-Duty Laboratory Use with reliability suited for routine daily nitrogen analysis.
- Compact & Modular Architecture that fits easily in modern lab setups and simplifies servicing.
- Multiple Program Storage: Supports saving multiple digestion, distillation, and titration programs internally.
- USB Backup & Restore: Users can export (download) all programs to a USB drive and import (load) programs from USB for quick setup, sharing, or recovery.
- Remote Monitoring & Control: Optional Labs Connect module enables secure internet-based access to start/stop operations, view live status, check errors, and monitor digestion/distillation/titration progress remotely.
- Multiple Program Storage: Supports saving multiple digestion, distillation, and titration programs internally.
- USB Backup & Restore: Users can export (download) all programs to a USB drive and import (load) programs from USB for quick setup, sharing, or recovery.
- Remote Monitoring & Control: Optional Labs Connect module enables secure internet-based access to start/stop operations, view live status, check errors, and monitor digestion/distillation/titration progress remotely.
SKU: DAN.NACOM.01 - Kjeldahl Instruments
Automatic Solvent Extraction System
Safety Features
- Standalone housing for Temperature controller to protect electronics from solvent area & heat zone.
- PC chart software performs Live graphical representation of time/temperature gradient on PC Connectivity
- Auto Alarm for recovery phase
- Auto power off mode on completion of extraction.
- Independent loading of sample with individual mechanical controls.
- Inbuilt safety features like auto error indication, auto over temperature protection and auto sensor break protection.
- Cold water line for condensation of solvent with silicon hose interconnection for condensor
SKU: DAN-6T-02
